| MODEL NAME |
TITAN-S100 |
TITAN-S200 |
TITAN-S300 |
| System |
CPU |
Intel Celeron N2807
(Dual Core 2.16GHz) |
Intel Celeron N3160
(Quad Core 2.24GHz) |
Intel Celeron J1900
(Quad Core up to 2.4GHz) |
| Storage |
HDD: 320GB
SSD: 256GB/128GB/64GB
mSATA: 256GB/128GB/64GB |
HDD: 320GB
SSD: 256GB/128GB/64GB
mSATA: 256GB/128GB/64GB |
HDD:320GB
mSATA:256GB/128GB/64GB
mSATA:256GB/128GB/64GB |
| RAM |
DDR III 1Slot
(Up to 4GB) |
DDR III 1Slot
(Up to 8GB) |
DDR 1Slot
(Up to 8GB) |
| Display |
Size |
15' LED LCD (1024 x 768) |
| Input |
5W Resistive Touch
PCAP Touch (Optional) |
| I/O |
Serial |
3 Ports (RI/5V/12V BIOS Selectable) |
3 Ports (RI/5V/12V BIOS Selectable) |
3 Ports (RI/5V/12V BIOS Selectable) |
| Parallel |
1 Port (Optional) |
1 Port (Optional) |
1 Port (Optional) |
| USB |
6 Ports (USB 2.0) |
6 Ports
(2Ports USB 2.0/2Ports USB 3.0 -REAR )
(2Ports USB 2.0-SIDE) |
6 Ports
(5Ports USB 2.0, 1Port USB 3.0) |
| PS/2 |
- |
- |
- |
| HDMI |
|
- |
- |
| Ethernet |
1 Port |
1 Port |
1 Port |
| VGA |
1 Port |
1 Port |
1 Port |
| Drawer |
1 Port / 2 CH
(12V/24V Selectable) |
1 Port / 2 CH
(12V/24V Selectable) |
1 Port / 2 CH
(12V/24V Selectable) |
| Audio |
1 Port (Line out) |
1 Port (Line out) |
1 Port (Line out) |
| Peripherals |
Internal Printer |
- |
| MSR |
1/2/3 Track Support (USB) |
| Scanner |
- |
| Fingerprint Reader |
- |
| Dallas Key |
- |
| Customer Display |
15' LED LCD (1024 x 768) Normal/Flat |
| 9.7' LED LCD (1024 x 768) Flat |
VFD (20CH x 2Line)
VFD (256 x 32 Graphic) |
| Expansion Slot |
mini PCIe Slot x 1 |
mini PCIe Slot x 1
|
mini PCIe Slot x 1 |
| Specific Option |
VESA Wall Mount, V stand |
| Software |
OS |
POSReady 7
Win 8.1 Industry (Retail),
Win 10 IoT Enterprise (Retail) |
POSReady 7
Win 8.1 Industry (Retail),
Win 10 IoT Enterprise (Retail) |
POS Ready 7
Win 8.1 Industry (Retail),
Win 10 IoT Enterprise (Retail) |
| Power supply |
DC 12V/5A |
제조사/브랜드 : Sam4s
